Hydrant Standpipes

We make single and twofold hydrant standpipes from high quality die-casted, gravity casted and forged materials that meet DIN and EN standards. This makes them quick, and easy to use in fire fighting. For more further information and order, please contact us.

Single and double underground hydrant standpipes

  • DN 50

    rocniki sztrog 0024 111020 rocniki sztrog 0027 111017 DN50 1xC s ventilom

    C

    2C

    C with valve

    • Inlet d(mm) Ø 50
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 905
    • Weight (kg) 3,70 - 3,90
    • Inlet d(mm) Ø 50
    • Outlet 2C
    • Width B(mm) 330
    • Height H(mm) 965
    • Weight (kg) 5,10 - 5,30
    • Inlet d(mm) Ø 50
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 985
    • Weight (kg) 4,80

    DN 50 (31 KB)

  • DN 50 - extended

    rocniki sztrog 0023 111021 rocniki sztrog 0011 111033 DN50 1xC s ventilom podaljsana cev

    C

    2C

    C with valve

    • Inlet d(mm) Ø 50
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 1805
    • Weight (kg) 5,35 - 5,54
    • Inlet d(mm) Ø 50
    • Outlet 2C
    • Inlet B(mm) 330
    • Height H(mm) 1805
    • Weight (kg) 5,10 - 5,30
    • Inlet d(mm) Ø 50
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 1885
    • Weight (kg) 6,40

    DN 50 - extended (32 KB)

  • DN 50 - extension of standpipe

    rocniki sztrog 0021 111023 rocniki sztrog 0009 111035

    C

    2C

    • Inlet d(mm) Ø 50
    • Outlet C
    • Width B(mm) 370
    • Height H(mm) 920
    • Weight (kg) 3,50 - 3,70
    • Inlet d(mm) Ø 50
    • Outlet 2C
    • Width B(mm) 330
    • Height H(mm) 980
    • Weight (kg) 5,20 - 5,40

    DN 50 - extension of standpipe (33 KB)

  • DN 80

    rocniki sztrog 0037 111007 rocniki sztrog 0041 111003 rocniki sztrog 0039 111005 rocniki sztrog 0043 111001 DN80 1xC s ventilom

    B

    2B

    C

    2C

    C with valve

    • Inlet d(mm) Ø 80
    • Outlet B
    • Width B(mm) 330
    • Height H(mm) 905
    • Weight (kg) 4,20 - 4,40
    • Inlet d(mm) Ø 80
    • Outlet 2B
    • Width B(mm) 330
    • Height H(mm) 1015
    • Weight (kg) 6,60 - 6,80
    • Inlet d(mm) Ø 80
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 905
    • Weight (kg) 4,00 - 4,20
    • Inlet d(mm) Ø 80
    • Outlet 2C
    • Width B(mm) 330
    • Height H(mm) 970
    • Weight (kg) 5,50 - 5,70
    • Inlet d(mm) Ø 80
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 985
    • Weight (kg) 5,10

    DN 80 (32 KB)

  • DN 80 - extension of standpipe

    rocniki sztrog 0019 111025 rocniki sztrog 0001 111043 rocniki sztrog 0018 111026 rocniki sztrog 0003 111041

    B

    2B

    C

    2C

    • Inlet d(mm) Ø 80
    • Outlet B
    • Width B(mm) 330
    • Height H(mm) 920
    • Weight (kg) 4,30 - 4,50
    • Inlet d(mm) Ø 80
    • Outlet 2B
    • Width B(mm) 330
    • Height H(mm) 1030
    • Weight (kg) 6,70 - 6,90
    • Inlet d(mm) Ø 80
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 920
    • Weight (kg) 4,10 - 4,30
    • Inlet d(mm) Ø 80
    • Outlet 2C
    • Width B(mm) 330
    • Height H(mm) 985
    • Weight (kg) 5,60 - 5,80

    DN 80 - extension of standpipe (33 KB)

  • DN 100

    rocniki sztrog 0029 111015 rocniki sztrog 0033 111011 rocniki sztrog 0031 111013 rocniki sztrog 0035 111009

    B

    2B

    C

    2C

    • Inlet d(mm) Ø 100
    • Outlet B
    • Width B(mm) 330
    • Height H(mm) 950
    • Weight (kg) 6,90 - 7,10
    • Inlet d(mm) Ø 100
    • Outlet 2B
    • Width B(mm) 330
    • Height H(mm) 1025
    • Weight (kg) 9,20 - 9,40
    • Inlet d(mm)Ø 100
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 950
    • Weight (kg) 6,90 - 7,10
    • Inlet d(mm) Ø 100
    • Outlet 2C
    • Width B(mm) 330
    • Height H(mm) 980
    • Weight (kg) 8,20 - 8,40

    DN 100 (34 KB)

  • DN 100 - extension of standpipe

    rocniki sztrog 0013 111031 rocniki sztrog 0007 111037 rocniki sztrog 0029 111015 rocniki sztrog 0005 111039

    B

    2B

    C

    2C

    • Inlet d(mm)Ø 100
    • Outlet B
    • Width B(mm) 330
    • Height H(mm) 930
    • Weight (kg) 7,00 - 7,20
    • Inlet d(mm) Ø 100
    • Outlet 2B
    • Width B(mm) 330
    • Height H(mm) 1025
    • Weight (kg) 9,30 - 9,50
    • Inlet d(mm) Ø 100
    • Outlet C
    • Width B(mm) 330
    • Height H(mm) 930
    • Weight (kg) 6,90 - 7,10
    • Inlet d(mm) Ø 100
    • Outlet 2C
    • Width B(mm) 330
    • Height H(mm) 995
    • Weight (kg) 8,20 - 8,50

    DN 100 - extension of standpipe (33 KB)
